Grand Canyon 18" to 96" H-Style Outdoor Glass Burner
The Grand Canyon H-Style Outdoor Glass Burner is a vented burner for a contemporary fire of glass or lava instead of logs. The H-shaped burner spreads the flame across the firebox. This version is built from 304 stainless steel, for outdoor fireplaces under a patio cover, and ships match-lit so you can add the control system you want.
It comes in 10 sizes from 18" to 96". Model numbers are GLASSBRN-##/12-H-SS for 18" to 30" and GLASSBRN-##/14-H-SS for 36" and larger, where ## is the size. The burner is built for natural gas; choosing propane adds the LP conversion kit (LP-CONV). Media is sold separately.
What's Included
- H-style glass burner
- Flex line and inlet fitting
- Damper clamp
- LP conversion kit (propane option only)
- Rating plate and manual
Key Features
- 10 sizes: 18", 24", 30", 36", 42", 48", 60", 72", 84", 96"
- 52,000 to 175,000 BTU on natural gas across the 18" to 60" sizes
- 304 stainless steel; indoor use or outdoor under a patio cover
- Ships match-lit; add a control system if you want a pilot or remote
- Natural gas burner; propane option adds the LP conversion kit
- Gas inlet 1/2" NPT
- Vented: the fireplace damper must be locked open with the included damper clamp
- Tested to ANSI Z21.60 for decorative gas appliances in solid-fuel fireplaces
- Media is required and sold separately (see below)
What to Order With It
The burner needs a bed of media to finish the fire. Use no more than one layer over the burner tube.
Required (choose one):
Optional controls:
For sizes above 60", tell us the size and fuel and we will confirm the right control.
Optional:
Specifications
| Size |
Model |
BTU Natural Gas |
BTU Propane (with LP-CONV) |
| 18" |
GLASSBRN-18/12-H-SS |
52,000 |
49,000 |
| 24" |
GLASSBRN-24/12-H-SS |
64,000 |
64,000 |
| 30" |
GLASSBRN-30/12-H-SS |
76,000 |
79,000 |
| 36" |
GLASSBRN-36/14-H-SS |
81,000 |
83,000 |
| 42" |
GLASSBRN-42/14-H-SS |
86,000 |
87,000 |
| 48" |
GLASSBRN-48/14-H-SS |
150,000 |
145,000 |
| 60" |
GLASSBRN-60/14-H-SS |
175,000 |
165,000 |
| 72" |
GLASSBRN-72/14-H-SS |
Not published |
Not published |
| 84" |
GLASSBRN-84/14-H-SS |
Not published |
Not published |
| 96" |
GLASSBRN-96/14-H-SS |
Not published |
Not published |
| Vent Type |
Vented |
| Manifold Pressure |
3.5" W.C. natural gas, 10" W.C. propane |
| Inlet Pressure |
4.5" to 7" W.C. natural gas, 11" to 14" W.C. propane |
| Gas Inlet |
1/2" NPT |
| Glass Media |
24" burner 10 lbs, 36" burner 15 lbs, 48" burner 20 lbs, 60" burner 25 lbs. Ask us for other sizes. |
| Standard |
ANSI Z21.60 |
Minimum Fireplace Dimensions
Measure the empty firebox: front opening width, back width, depth and height. These are the smallest fireboxes each size will fit.
| Burner Size |
Front Width |
Back Width |
Depth |
Height |
| 18" |
30" |
18" |
14" |
10" |
| 24" |
36" |
24" |
14" |
10" |
| 30" |
42" |
30" |
16" |
10" |
| 36" |
48" |
36" |
16" |
10" |
| 42" |
54" |
42" |
16" |
10" |
| 48" |
60" |
48" |
16" |
10" |
| 60" |
72" |
60" |
16" |
10" |
| 72" |
Not published |
Not published |
Not published |
Not published |
| 84" |
Not published |
Not published |
Not published |
Not published |
| 96" |
Not published |
Not published |
Not published |
Not published |
With the battery electronic ignition system the firebox must be wider: 18" burner 36" front and 24" back; 24" burner 42" front and 30" back; 30" burner 48" front and 36" back; 36" burner 54" front and 42" back; 42" burner 60" front and 48" back.
Grand Canyon does not publish ratings or firebox minimums for sizes above 60". Call us with your firebox measurements before ordering.
Keep glass doors fully open while the burner is running, and keep furniture at least 36" from the front. Not for installation in manufactured or mobile homes.
Warranty
Burner: lifetime warranty against manufacturing defects or breakage, indoors or outdoors, when installed by a professional installer. Natural browning of the stainless finish is not covered. Warranty is limited to the original purchaser.
