Empire Tahoe Deluxe 32" Direct Vent Gas Fireplace

Empire Tahoe Deluxe 32" Direct Vent Gas Fireplace

The Empire Tahoe Deluxe 32" Direct Vent Fireplace models feature our Contour tube-style burner, designed to complement the hand-painted ceramic fiber log set, and produce a natural dancing flame.

The Empire Tahoe Deluxe model has louvers and an available trim kit. The large heat-resistant, tempered glass window provides an unobstructed view to the log set. Tahoe Deluxe models offer several styles of liners – Aged Brick, Herringbone, Stacked Limestone, and Black Reflective.

Tahoe Deluxe models require just 16 inches of depth making them ideal for applications where wall-cavity space is tight.

Features

• Contour Tube-Style Burner: Creates a natural, dancing flame that enhances realism and complements the hand-painted ceramic fiber log set.

• Decorative Louvers & Trim Kits: Included for a finished, customizable appearance.

• Large Tempered Glass Window: Heat-resistant glass offers a wide, unobstructed view of the log set.

• Multiple Liner Options: Choose from Aged Brick, Herringbone, Stacked Limestone, or Black Reflective for a personalized interior look.

• Compact Installation Depth: Requires only 16 inches of depth, ideal for tight wall-cavity applications.

What to Order With It

Required (choose one: barrier, or door frame with barrier plus a door set):

• Barrier, Black (DVFB32SBL)
• Door Frame with Barrier, Black (DVWB1BL)

Required (venting, order separately):

• 4 x 6 5/8. See the installation manual for vent kits and limits.

Optional – Remotes and wall controls:

• Remote, Battery Receiver/Remote, On/Off (FRBC)
• Remote, Battery Receiver/Remote, Thermostat (FRBTC2)
• Remote, Electric Receiver/Battery Remote, On/Off (FREC)
• Remote, Battery Receiver/Remote, TouchScreen, Programmable (FRBTPS)
• Wall Switch, On/Off (FWS1)
• Wall Thermostat, Reed Switch (TMV)
• Wall Thermostat, Wireless (TRW)

Optional – Variable remote kit (IP models):

• Remote, Var Flame Kit, NG (RVKN)
• Remote, Var Flame Kit, LP (RVKP)

Optional – Accessories:

• Blower, Auto (FBB4)
• Flex Gas Line, 24-in. Stainless Steel (GF24)
• Platinum Embers (PE20)
• Ember Kit (EK1)

Optional – Door sets (require the door frame with barrier):

• Door Set, Black, Arch (DVRB1CBL)
• Door Set, Black, Mission Arch (DVRB1MBL)
• Door Set, Black, Rectangle (DVDB1CBL)
• Door Set, Black, Mission Rectangle (DVDB1MBL)

Optional – Fronts and frames:

• Steel Frame, Black (DVF1BL)
• Steel Frame, Hammered Pewter (DVF1HP)
• Trim Kit, Bottom, Hammered Pewter (FBS1HP)
• Louvers, Black, Mission (DVG1MBL)
• Louvers, Hammered Pewter, Mission (DVG1MHP)
• Louvers, Black, Arch (DVG1ABL)
• Louvers, Hammered Pewter, Arch (DVG1AHP)

Optional – Liners:

• Liner, Aged Brick (DVP1SA)
• Liner, Stacked Limestone (DVP1SG)
• Liner, Herringbone Brick (DVP1SH)
• Liner, Black Porcelain (DVP1SKR)

Optional – Gas conversion kits:

• Conversion Kit, NG To LP (18456)
• Conversion Kit, LP To NG (18816)
• Conversion Kit, IPI (NG To LP) (32880)
• Conversion Kit, IPI (LP To NG) (32881)

Specifications

Installation Requirements

• Clearances to combustibles: Back 0", sides 0", floor 0", top standoffs 0", top framing edge 3"
• Mantel clearance: Follow the mantel chart in the installation manual for any combustible mantel above the unit.
• Venting: 4" x 6-5/8" direct vent, top or rear
• Gas input (BTU/hr): Natural gas 18,000 max / 14,000 min; propane 18,000 max
• Power: Millivolt models (FP30, FP31) need no electricity to run the burner. Intermittent pilot models (FP70, FP71) ship with 4 AA batteries and a power adapter.
• Installation: Must be installed by a qualified installer per the installation manual and local codes.
