The Sierra Flame Thompson 36 is a compact direct vent gas fireplace that puts out 26,000 Btu/hr from a 36" unit. It comes in the deluxe version only, with the black trim and safety barrier attached, black porcelain panels, a 4-piece log set, a deluxe remote, fan kit and modulating valve.
Key Features
- 26,000 Btu/hr on high, 18,000 on low
- Trim and safety barrier included (attached to the unit)
- Deluxe remote, fan kit and modulating valve
- Electronic ignition
- Black porcelain panels and 4-piece log set included
- Borosilicate glass
What to Order With It
- Venting (4" x 7" direct vent, top vent only): 4" x 7" venting parts (termination kit, flex, couplers and hard-pipe adapters).
- Propane: choose the Liquid Propane option above. To convert a natural gas unit later, order the THOM-LP-KIT conversion kit.
Specifications
| Models |
THOMPSON-36-DELUXE-NG (natural gas), THOMPSON-36-DELUXE-LP (propane) |
| Type |
Direct vent |
| Input |
Natural gas: 26,000 / 18,000 Btu/hr (high / low)
Propane: 26,000 / 18,000 Btu/hr (high / low) |
| Venting |
4" x 7" top vent |
| Framing (W x H x D) |
38" W x 37" H x 15" D |
| Glass viewing area |
16 1/2" H x 29" W |
| Efficiency |
67.68% (natural gas) |
Installation must be done by a licensed gas fitter or qualified technician, following the installation manual and local codes. Check the manual for clearances, venting runs and framing details before you build.
Downloads
Warranty
Sierra Flame gas fireplace limited warranty: five years against defects in materials and workmanship on the combustion chamber, heat exchanger and burners (and stainless steel parts against tarnishing); one year on electrical and wear parts such as blowers, gas valves, switches, wiring, remote controls, igniters, gaskets, glass (thermal damage only) and pilot assemblies. It covers the original purchaser from an authorized Sierra Flame dealer and requires installation by a licensed technician to the manual and local codes. Labor, venting components, and damage from water, weather or chemical cleaners are not covered. Read the full terms in the Sierra Flame Gas Fireplace Warranty (2024).
