Fire Magic 3278-52 Insulating Liner for Power Burners & Double Searing Stations

Fire Magic 3278-52 Insulating Liner for Power Burners & Double Searing Stations

The Fire Magic 3278-52 is the insulating liner for Fire Magic power burners and double searing stations. It lets the unit install in an enclosure built of combustible materials, provided the countertop is non-combustible.

Key Features

• Insulating liner for Fire Magic power burners and double searing stations
• For combustible enclosures with a non-combustible countertop
• Hangs from the countertop on its liner hangers

What to Order With It

Fits:

• Echelon Diamond Power Burner
• Aurora Power Burner
• Classic Power Burner

Specifications

• Part number: 3278-52
• Fits: Fire Magic power burners and double searing stations
• Enclosure cut-out: 23" W x 20 7/8" D x 12 1/4" H (countertop to unit bottom)
• Liner flange width: 24 1/8" (enclosures with countertop overhang)
• Use: Outdoor
• Shipping weight: 38 lbs

Fire Magic instructions: the liner is only for an enclosure built of combustible materials with a NON-COMBUSTIBLE countertop, and it hangs from the countertop on its liner hangers. Do not let the appliance hanger touch the countertop or any combustible surface, and provide enclosure openings for drainage, replacement air and cross-ventilation.

Documents & Downloads

• Accessory Insulating Liner Instructions (52 Series)
• Fire Magic Warranty
• Fire Magic Catalog

Warranty

• Covered by the Fire Magic limited warranty; see the warranty link above for coverage terms

Warranty applies to the original purchaser with proof of purchase, for single family residential use.
