Empire Aspen 60" Traditional Outdoor Wood Burning Firebox
Free Shipping over $299
Please contact us directly to request quote for Empire products.
Free Shipping over $299
Please contact us directly to request quote for Empire products.
The Empire Aspen 60" Traditional is an outdoor wood burning fireplace firebox, listed to UL 127, with a 60" wide by 38" high opening.
Model number OWB60FB0F comes with a mesh pull screen, grate and grate retainer brackets. Finish the interior with a smooth concrete liner kit in one of four colors or with buff, red or soapstone firebrick, and vent it through Empire's 12" WB12V chimney with a cap.
The firebox needs at least 1 1/2" of air space to combustibles at the back and sides (1/2" at the nailing flanges), with the opening at least 24" from a sidewall. A mantel can sit 18" or more above the opening, up to 10" deep, and a non-combustible hearth extension is required when the firebox sits on a combustible floor.
The chimney uses only Empire 12" WB12V components, at least 20 ft tall (22 ft with two offsets) and no more than 90 ft, with a firestop wherever it passes through a ceiling or floor. The firebox sheds moderate amounts of water, so follow the moisture section of the manual, and keep it away from doors, walkways and small isolated spaces.
See more in our outdoor wood fireplaces collection, or browse all outdoor fireplaces.
Planning the space? Our outdoor fireplace ideas guide walks through eight setups and the fireplaces that fit them. Comparing wood heat options? Our guide to types of wood burning fireplaces covers open, EPA-certified, insert and outdoor designs.
An interior liner (a concrete liner kit or two crates of firebrick), the 12" chimney and a cap are required and ordered separately, plus a hearth extension on a combustible floor (see below).
Order a liner kit or firebrick, the chimney and a cap with the firebox.
Interior liner (one required): a smooth concrete liner kit
Or firebrick (2 crates required; Heat Stop mortar must be used with soapstone):
Chimney (12" Empire components, required):
Chimney cap (one required):
Hearth extension (required on a combustible floor):
| Model numbers | OWB60FB0F |
|---|---|
| Type | Outdoor wood burning fireplace (firebox) |
| Opening | 60" wide x 38" high |
| Fuel | Wood; processed firelogs only if evaluated for fireplace use |
| Included | Mesh pull screen, grate and grate retainer brackets |
| Interior | Required: concrete liner kit or firebrick, ordered separately |
| Chimney | 12" Empire WB12V components; 20 ft minimum, 90 ft maximum |
| Clearances | 1 1/2" back and sides; 0" at the standoffs and header brackets; opening 24" from a sidewall |
| Mantel | 18" minimum above the opening, 10" maximum depth |
| Safety listing | UL 127 |
For a smooth interior, choose a concrete liner kit in gray (WBL60SGR), black (WBL60SBL), white (WBL60SWH) or mocha (WBL60SBR). For a brick look, order two 50-piece crates of buff (WBL60BBK), red (WBL60RBK) or soapstone (WBL60SBK) split firebrick; soapstone must be laid with Heat Stop mortar (WBBKM).
Top the chimney with a round (WB12VRCC), rain (WB12VRC) or black pyramid (WB12VPC) cap. On a combustible floor, add the 60" hearth extension kit (WB60HE) or the shallow version (WB60SHE).
The Aspen 60" Traditional suits an outdoor living space where you want a wide wood fire with a 38" tall opening.
Reach out to our team and we will help you list the liner, chimney sections, cap and hearth extension for your build.
Which Aspen is right for me?
The Aspen 60" Traditional has the taller 38" opening and a published installation manual. We carry two Aspen 60" outdoor wood burning fireboxes. The Aspen 60" Traditional has a 60" wide by 38" high opening, comes with a mesh pull screen and grate, is finished inside with a concrete liner kit or firebrick, and vents through Empire's 12" WB12V chimney; its installation manual is on its page. The Aspen 60" Linear has a wide, low view of about 60" x 24", a mesh pull screen and smooth brick liner sets in four colors; Empire has not yet published its installation manual, so reach out to our team before ordering it.
What do I need to order with it?
An interior liner (one concrete liner kit, or two crates of firebrick), Empire 12" WB12V chimney components, a chimney cap and, on a combustible floor, a hearth extension kit. The mesh pull screen and grate come with it.
Can it be used indoors?
No. The Aspen 60" Traditional is for outdoor use only.
How tall does the chimney need to be?
At least 20 ft (22 ft with two offsets) and no more than 90 ft, built only from Empire 12" WB12V components, with no more than two pairs of 30° or smaller offsets and a 2" air space to insulation and framing around the chimney.
What clearances does it need?
At least 1 1/2" of air space to combustibles at the back and sides (1/2" at the nailing flanges), the opening at least 24" from a sidewall, and the non-combustible zone in front shown in the manual. Do not pack the air spaces with insulation.
What can I burn in it?
Wood. Use processed firelogs only if they have been evaluated for fireplace use.
Can I burn gas in it?
Only with the optional components specified in the manual. A gas log set, gas insert or log lighter should go in when the fireplace is built, with the gas installed to the National Fuel Gas Code.
Empire limited warranty, from the warranty section of the installation manual:
The warranty is for the original purchaser. Travel, diagnostic and freight charges and removal and reinstallation costs are not covered. Full terms are in the warranty section of the installation manual.
