TrueFlame 22" 4.3 Cu. Ft. Deluxe Compact Refrigerator - AMD-RFR-22D
The AMD-RFR-22D is the deluxe version of AMD Direct's 22" compact refrigerator, with an upgraded #304 stainless steel door and handle, sold under the TrueFlame name. It holds 4.3 cu. ft. and is hinged on the right with the handle on the left. The manual says it is designed to be freestanding only, with 5" of space at the back and sides.
What's Included
- 3 shelves
- 1 glass lid
- 1 crisper
- Instruction manual
- Deluxe door handle kit: door handle, 2 refrigerator door screws, 2 handle screw assemblies, hex wrench
Key Features
- 4.3 cu. ft. capacity
- Upgraded #304 stainless steel door and handle
- Hinge on the right, handle on the left
- Locking door
- Black interior with black wire racks
- Temperature control dial, OFF to 6
- Interior LED light that turns on when the door opens
- Two leveling legs
Specifications
| Model Number |
AMD-RFR-22D |
| Capacity |
4.3 cu. ft. |
| Installation |
Freestanding only |
| Door |
#304 stainless steel door and handle; hinge on right, handle on left; locking |
| Temperature control |
Dial, OFF to 6 |
| Shelving |
3 shelves, 1 glass lid, 1 crisper |
| Electrical |
115 V AC, 60 Hz |
| Certification |
ETL, DOE, CE (manufacturer data sheet) |
Dimensions
| Overall (W x D x H) |
21.3" W x 21.3" D x 33.5" H |
| Clearance |
5" at back and sides (freestanding only) |
Installation
- Freestanding only. The manual states this appliance should not be recessed or built in.
- Allow 5" of space at the back and sides of the unit.
- Recommended ambient: 60°F to 90°F. Keep away from direct sunlight and heat sources, and avoid moist areas.
- Power: 115 V AC, 60 Hz, three-prong grounded outlet.
- Fuse or circuit breaker: 1.3 amperes. Use its own individual outlet; an extension cord is not recommended.
Please Note
- This refrigerator is freestanding only. Do not build it into an island or recess it into a cabinet.
- Some manufacturer documents list 4.1 cu. ft.; the 4.3 cu. ft. figure is from the manual.
Warranty
AMD Direct's warranty for 22" refrigeration models gives 1 year on all construction and electrical components, including the compressor, transformer, LED bulbs, LED harness, power source wire, LED switches and interior halogen light wire/bulbs.
