Osburn Inspire 2000-I Wood Insert
This wood insert will bring an unmatched modernism to your decor, in addition to perfectly combining functionality and comfort. The impeccable lines display a timeless style while guaranteeing reliability and durability.
Whether you want to enjoy a broad view of the flames in the comfort of your living room during a romantic evening or simply to benefit from impressive heat in cold weather, the Inspire will charm you as much by its aesthetics as by its 79% optimum overall efficiency and its 176 CFM blower — the strongest fan in the Osburn insert range.
At 2.3 g/h of particulate emissions with a high-performance combustion system, it is EPA 2020 certified. The Inspire Collection celebrates our past and embraces our future as our team is committed more than ever to our industry's contribution to sustainability.
Features
- Blower included, up to 176 CFM
- Heats 500 to 2,100 sq ft with up to 75,000 BTU/h
- 2.4 cu ft firebox that takes logs up to 20"
- Maximum burn time of 8 hours
- EPA 2020 approved, non-catalytic, 2.3 g/h average particulate emissions
- Ceramic glass door with steel frame and glass air-wash system
- Firebox lined with refractory bricks for better heat distribution
- Stainless-steel secondary-air system
- 3/16" steel body and 3/8" steel top
- Limited lifetime warranty
Will It Fit?
Measure your existing masonry fireplace opening before ordering. The Inspire 2000-I needs at least:
| Minimum fireplace opening height |
24 5/8" |
| Minimum fireplace opening width |
29" |
| Minimum fireplace opening depth |
20 3/4" |
| Fireplace type |
Masonry only — factory-built fireplaces are not permitted |
| Chimney liner |
6" listed liner required, minimum 12' height |
Note the 20 3/4" depth requirement — this is the deepest of the Osburn inserts, so a shallow hearth that takes the 1700-I or Matrix 1900 may not take the Inspire.
What to Order With It
The Inspire 2000-I Wood Insert needs a faceplate to be complete. Choose from each required group below.
Required – faceplate (choose one):
Optional:
Performance
| Maximum heat output (dry cordwood) |
75,000 BTU/h (22 kW) |
| Overall heat output range |
14,200 – 44,500 BTU/h (4.16 – 13.04 kW) |
| Recommended heating area |
500 – 2,100 sq ft (47 – 195 m²) |
| Average overall efficiency (HHV) |
72% |
| Average overall efficiency (LHV) |
77% |
| Optimum overall efficiency |
79% |
| Average particulate emissions |
2.3 g/h (EPA / CSA B415.1-10) |
| Average carbon monoxide |
69 g/h |
| Maximum burn time |
8 hours |
| Overall firebox volume |
2.4 cu ft (0.068 m³) |
| EPA loading volume |
1.95 cu ft (0.055 m³) |
| Recommended log length |
16" (406 mm), loaded east-west |
| Blower |
Included, up to 176 CFM |
Specifications
| Combustion technology |
Non-catalytic |
| High-efficiency certified appliance |
Yes, EPA 2020 approved |
| Fuel type |
Dry cordwood |
| Maximum log length |
20" |
| Log positioning |
Loading over width |
| Chimney diameter |
6" |
| Flue outlet diameter |
6" |
| Type of chimney |
Liner - UL1777 |
| Minimum liner height (feet) |
12' |
| Baffle type |
C-Cast |
| Approved for an alcove installation |
No |
| Approved for a mobile home installation |
No |
| Fireplace type |
Masonry only |
| Shipping weight (without options) |
420 lb (191 kg) |
| Appliance weight (without options) |
380 lb (172 kg) |
| Door type |
Single, glass with steel frame |
| Glass type |
Ceramic glass |
| Glass surface – dimensions (Width X Height) |
20 1/4" X 9 1/2" |
| Glass air-wash system |
Yes |
| Premium quality blower included (CFM) |
176 |
| Overall dimension (Height) |
24 3/8" |
| Overall dimension (Width) |
28 1/2" |
| Overall dimension (Depth) |
20 7/8" |
| Door opening – dimension (Height) |
8 1/4" |
| Door opening - dimension (Width) |
20" |
| Firebox – dimension (Height) |
11 3/4" |
| Firebox – dimension (Width) |
21" |
| Firebox – dimension (Depth) |
16 3/4" |
| Fireplace opening – minimum (Height) |
24 5/8" |
| Fireplace opening – minimum (Width) |
29" |
| Fireplace opening – minimum (Depth) |
20 3/4" |
| Firebox lined with refractory bricks for better heat distribution |
Yes |
| Stainless-steel secondary-air system improving gas combustion |
Yes |
| Steel thickness – body |
3/16" |
| Steel thickness – top |
3/8" |
| USA standard (emissions) |
EPA |
| USA standard (safety) |
UL 1482, UL 737 |
| Tested and listed as per applicable standards |
By an accredited laboratory |
| Warranty |
Limited lifetime |
