The Kingsman 33" ZCV34 Zero Clearance Direct Vent Gas Fireplace combines durable steel construction with a premium pan burner, realistic flames, and versatile media. Designed for new construction or renovation, this zero clearance gas fireplace delivers efficient warmth and timeless style.
With up to 85% maximum efficiency, sealed combustion, and clean-view design, the Kingsman gas fireplace enhances any room. Customize it with millivolt or IPI ignition, brick or porcelain liners, and multiple surround options.
Features
-
Millivolt or IPI Valve System – Choose a flexible ignition system designed for convenient fireplace operation and dependable performance.
-
Power Outage Operation – The millivolt system allows the gas fireplace to operate during a power failure, providing reliable heat when electricity is unavailable.
-
Hi/Low Heat & Flame Adjustment – Easily adjust heat output and flame height for personalized comfort, ambiance, and energy-efficient operation.
-
Zero Clearance Design – Engineered for zero clearance fireplace installations, making it an ideal solution for space-conscious residential applications.
-
Direct Vent Gas Fireplace – Sealed direct vent technology provides efficient combustion while helping maintain indoor air quality.
-
Safety Screen Barrier – Includes a protective safety screen barrier designed to help reduce accidental contact with the hot fireplace glass.
-
33-Inch Gas Fireplace – Compact 33-inch design delivers a stylish focal point and supplemental warmth for living rooms, bedrooms, and other interior spaces.
Specification
| Specification |
ZCV34N / ZCV34NE |
ZCV34LP / ZCV34LPE |
ZCV34NH / ZCV34NHE |
ZCV34LPH / ZCV34LPHE |
| Fuel |
Natural Gas |
Propane |
Natural Gas |
Propane |
| Flue |
Top |
Top |
Top |
Top |
| Gas Control |
Millivolt / IPI |
Millivolt / IPI |
Millivolt / IPI |
Millivolt / IPI |
| Input Max. |
19,000 BTU |
18,000 BTU |
19,000 BTU |
18,000 BTU |
| Input Min. |
13,500 BTU |
14,000 BTU |
13,500 BTU |
14,000 BTU |
| FE (P.4.1-02) |
53.49% / 56.14% |
58.67% / 61.17% |
63.25% / 66.45% |
66.38% / 69.25% |
| Venting |
4”/7” Flex or 4 x 6 5/8 Hard Pipe* or Power Vent |
4”/7” Flex or 4 x 6 5/8 Hard Pipe* or Power Vent |
4”/7” Flex or 4 x 6 5/8 Hard Pipe* or Power Vent |
4”/7” Flex or 4 x 6 5/8 Hard Pipe* or Power Vent |
| Viewing Area |
28 5/8" W x 25 3/8" H |
28 5/8" W x 25 3/8" H |
28 5/8" W x 25 3/8" H |
28 5/8" W x 25 3/8" H |
| Glass Type |
Tempered |
Tempered |
Ceramic |
Ceramic |
| Certification |
Heater |
Heater |
Heater |
Heater |
| Actual Width (CVCK) |
33” |
33” |
33” |
33” |
| Actual Height (CVCK) |
36" |
36” |
36" |
36” |
| Actual Depth (CVCK) |
18 1/16” |
18 1/16” |
18 1/16” |
18 1/16” |
| Actual Width (Louvers) |
— |
— |
— |
— |
| Actual Height (Louvers) |
— |
— |
— |
— |
| Actual Depth (Louvers) |
— |
— |
— |
— |
| Power Vent |
Yes |
Yes |
Yes |
Yes |
