| 4/7" Direct Vent to 4" B-Vent Converter - F35BVC |
|
|
Place a bead of Black Mil Pac sealant around a 4-inch flue collar on the stove. Venting adapter, Converter - 4/7" DV to 4" B-Vent.
|
| 7" Decorative Black Collar - F7DBC |
|
|
Designed to trim around the exposed vent pipes as they enter a wall or ceiling, this stamped steel trim will make it a touch less ugly, and with being painted black.
|
Horizontal Vent Starter Kit - FDVHSK
|
|
|
This starter kit has all the right pieces necessary to supply adequate ventilation to a direct vent stove. |
| Vertical Vent Starter Kit - FDVVSK |
|
|
Vertical Vent Starter Kit for Direct Vent Stoves is that the right accompaniment to anyone's direct vent stove. This vertical vent starter kit includes an attic insulation shield, fire stop, a ceiling trim plate, a black trim ring, roof support, 6 spacer springs, and mill pac. |
| Dura-Vent Stove Adapter - ZDVDKA |
|
|
Dura-vent stove adapter is used specifically with direct vent stoves and allows the ventilation to exceed expectations when comparing them to other vents. |
| 45-Degree DirectVent Pro Elbow - 46DVA-E45, 46DVA-E45B |
 |
Use to offset obstructions as needed. Fully unitized, twist-lock construction. Elbows swivel, allowing the lock to remain fully engaged while aligning to the desired direction. The angle will remain fixed at 45°. Finish: Galvanized & Black. |
90-Degree DirectVent Pro Elbow - 46DVA-E90B, 46DVA-E90
|
 |
Use to offset obstructions as needed. Fully unitized, twist-lock construction. Elbows swivel, allowing the lock to remain fully engaged while aligning to the desired direction. The angle will remain fixed at 90°. Finish: Galvanized & Black. |
| 17" DirectVent Pro Elbow Strap - 46DVA-ES |
 |
DirectVent Pro Elbow Strap Use for supporting vent pipe between offsets. |
| 4"x6.625" DirectVent Pro Pipe Length |
|


|
Features a fully unitized twist-lock construction in both 4” x 6 5⁄8” and 5” x 8” vent sizes. Use of sealant is optional unless specified by the appliance manufacturer. Finish: Galvanized & Black.
|
| 4"x6.625" DirectVent Pro Pipe Extension |
|


|
Use to add length to a straight length of DirectVent Pro. 8 ½” pipe adds 3”- 7” of length, 16” pipe adds 3”- 14 ½” of length when used with rigid sections of pipe. Direct vent lengths feature a fully unitized, twist-lock construction. Available in black or galvalume exterior.
|
| 4"x6.625" DirectVent Pro Adjustable Pipe |
|


|
Use of sealant is optional unless specified by the appliance manufacturer. Available in black or galvalume exterior. |
| DirectVent Pro Wall Strap - 46DVA-WS |
 |
Use to support vent pipe. Provides 1” clearance. Recommend installing Wall Straps at 4-foot intervals on vertical runs. |
| DirectVent Pro Ceiling Firestop - 46DVA-FS |
 |
Required for multi-story vertical installations on the second floor and any subsequent floors. |
DirectVent Pro Decorative Cover - 46DVA-DC
|
 |
Use as a decorative cover for horizontal (through-wall) installations Fits over the Wall Thimble faceplate. Also used to cover a Ceiling Support Box. |
| DirectVent Pro Attic Insulation Shield - 46DVA-IS |
 |
Required for installations that pass through an attic to prevent insulation and debris from accumulating near the vent. Provides 1” clearance to combustibles.
|
| 14" DirectVent Pro Cathedral Ceiling Support Box - 46DVA-CS |
 |
Use to pass through ceiling and support pipe. May be used on vaulted or flat ceilings. Painted black. Trim and clamp included. |
| DirectVent Pro Flat Roof Flashing - 46DVA-FF |
 |
Use to weatherproof the penetration of vent pipe through the roof. Use on flat roofs, chase enclosures, or masonry chimneys. Storm Collar required. Made of galvalume. |
| DirectVent Pro Adjustable Roof Flashing - 46DVA-F6 |
 |
Use to weatherproof the penetration of vent pipe through the roof. Select roof flashing based on pitch of the roof. For pitches of 0/12 - 6/12. Storm Collar required. Made of galvalume. |
| DirectVent Pro Steep Roof Flashing - 46DVA-F12 |
 |
Use to weatherproof the penetration of vent pipe through the roof. Storm Collar required. Made of galvalume. |
| DirectVent Pro Dead Soft Aluminum Flashings - 46DVA-F6DS |
 |
Available in sizes 4”x 6 5⁄8” and 5”x 8”, in 0/12-6/12 (shown) and 7/12-12/12 styles. Made of malleable dead soft aluminum. Use with metal or tile roofs. |
| DirectVent Pro Storm Collar - 46DVA-SC |
 |
Use to maintain a weather tight resistant seal between the pipe and the flashing. |
| DirectVent Pro High-Wind Termination Cap - 46DVA-VCH |
 |
Available in aluminum. Use for vertical terminations only. For vertical terminations only. Provides improved performance in high wind conditions. |
| DirectVent Pro Low-Profile Termination Cap - 46DVA-VC |
 |
Available in aluminum and stainless steel (S). Use for vertical terminations only. Check the appliance manufacturer’s instructions to determine which caps are approved for use with their appliance. |
| DirectVent Pro Wall Thimble - 46DVA-WT |
 |
Use with Square Horizontal Cap only. Provides a complete wall-pass-through and firestop. Refer to the appliance manufacturer’s installation instructions for requirements.
|
| DirectVent Pro Square Horizontal Termination Cap - 46DVA-HC |
 |
Use for standard and high-wind through-the-wall termination. Check installation instructions for restrictions on horizontal cap terminations. Available in aluminum, stainless steel (S), and copper (C). |
| DirectVent Pro Round Horizontal Termination Cap - 46DVA-HRCS |
 |
Use for through-the-wall termination. Check installation instructions for restrictions on horizontal cap terminations. Finish: aluminum.
|
| DirectVent Pro Snorkel Termination Cap - 46DVA-SNK14 / 36 |
 |
Use for horizontal through-the-wall termination when a vertical rise is desired in the system to meet the appliance manufacturer's recommended minimum heights. Do not enclose in the wall or install below grade. |
| DirectVent Pro Sconce Termination Cap - 46DVA-HSC |
 |
Use for horizontal through-the-wall termination. Check installation instructions for restrictions on horizontal cap terminations. Available in aluminum, stainless steel (S), and copper (C).
|
| DirectVent Pro Square Horizontal H2 Termination Cap - 46DVA-H2 |
 |
Use for standard and high-wind through-the-wall termination. Provides improved performance in high wind conditions. Adjustable air intake and interchangeable shroud. |
| DirectVent Pro High-Wind Sconce Termination Cap - 46DVA-HSCH |
 |
Use for horizontal through-the-wall termination. Provides improved performance in high wind conditions. Check installation instructions for restrictions on horizontal cap terminations. Available in aluminum, stainless steel (S), and copper (C).
|
| DirectVent Pro Snorkel H2 Termination Cap - 46DVA-H2-SNK14 |
 |
Use for horizontal through-the-wall termination when a vertical rise is desired in the system to meet the appliance manufacturer's recommended minimum heights. |
