DuraVent DuraTech LDC 10" Roof Radiation Shield HT
The DuraVent DuraTech LDC 10" Roof Radiation Shield HT is a critical chimney safety and roof penetration component designed for use with the DuraTech LDC all-fuel double-wall chimney system. Ideal for factory-built fireplaces, large masonry fireplaces, and vented non-condensing appliances, this roof radiation shield helps ensure safe passage through roof structures while maintaining proper chimney system clearance, fire safety, and code compliance in residential and commercial installations.
Engineered as part of a UL 103 Type HT listed chimney system, it supports diameters from 10" to 16" and features a solid-pack design with 1" ceramic insulation between a stainless steel inner wall and stainless or Galvalume outer jacket. It maintains a 2-inch clearance to combustibles and is tested to US and Canadian standards, delivering reliable chimney performance, thermal protection, and long-term safety in high-temperature venting applications.
Features
-
Essential Roof Chimney Safety Component: The DuraVent DuraTech LDC 10" Roof Radiation Shield HT is designed for use at the top of chase enclosures or where DuraTech LDC chimney pipe passes through the roof, ensuring safe and compliant installation.
-
Required for UL 103 Type HT Applications: Specifically engineered for UL 103 Type HT rated chimney systems, making it a critical component for high-temperature chimney venting safety compliance.
-
Multi-Plate Shield Design: Constructed using four integrated plates (included) that assemble to form a complete roof radiation shield for enhanced structural protection.
-
Improves Chimney Fire Safety: Helps maintain proper clearance and reduces heat transfer at roof penetrations, enhancing overall chimney system fire safety and thermal protection.
-
Insulation Pads Included: Each plate comes with factory-attached insulation pads, improving heat resistance and installation efficiency.
-
Compatible with DuraTech LDC Systems: Designed specifically for the DuraTech LDC 10-inch all-fuel double-wall chimney system, ensuring proper fit and performance.
Specification
| Specification |
Details |
| Model |
10DT-RRSHT |
| Series |
DuraTech LDC (10"-24") |
| Product Type |
Roof Radiation Shield HT |
| (Size) Inside Diameter |
10” |
| A |
11 1/4” |
| B |
15” |
| C |
3 1/4” |
