Osburn 1700 Wood Burning Stove
Designed to meet the needs of smaller spaces, the Osburn 1700 Wood Burning Stove is a faithful copy of the recently redefined 2000 model. This firebox combines robustness and elegance to allow you to enjoy your heating experience with confidence. This unit is equipped with high-density bricks, a cast iron door, a built-in ash pan, a top heat deflector that redirects heat to the front of the unit, and side panels to reduce its clearances.
Choose your favorite version by customizing the unit to suit your style: refined door overlays, new leg designs, glass ash lip; significant innovations for the most seasoned experts. At 2.4 g/h of particulate emissions the 1700 is EPA 2020 certified, and its 68% HHV overall efficiency puts it comfortably inside the high-efficiency band — so it qualifies wherever a certified clean-burning appliance is required.
Features
- Blower optional (sold separately)
- Heats 500 to 1,800 sq ft with up to 65,000 BTU/h
- 1.86 cu ft firebox that takes logs up to 18"
- Maximum burn time of 7 hours
- EPA 2020 approved, non-catalytic, 2.4 g/h average particulate emissions
- Ceramic glass door with cast iron frame and glass air-wash system
- Firebox lined with refractory bricks for better heat distribution
- Stainless-steel secondary-air system
- Approved for alcove installation, and for mobile homes with a fresh air intake
- 3/16" steel body and 5/16" steel top
- Limited lifetime warranty
What to Order With It
The 1700 Wood Stove needs a door overlay and a base to be complete. Choose from each required group below.
Required – door overlay (choose one):
Required – base (choose one):
Optional:
Performance
| Maximum heat output (dry cordwood) |
65,000 BTU/h (19 kW) |
| Overall heat output range |
9,800 – 52,200 BTU/h (2.87 – 15.3 kW) |
| Recommended heating area |
500 – 1,800 sq ft (46 – 167 m²) |
| Average overall efficiency (HHV) |
68% |
| Average overall efficiency (LHV) |
73% |
| Optimum overall efficiency |
76% |
| Average particulate emissions |
2.4 g/h (EPA / CSA B415.1-10) |
| Maximum burn time |
7 hours |
| Overall firebox volume |
1.86 cu ft (0.053 m³) |
| EPA loading volume |
1.44 cu ft (0.041 m³) |
| Recommended log length |
16" (406 mm), loaded east-west |
| Blower |
Optional |
Specifications
| Combustion technology |
Non-catalytic |
| High-efficiency certified appliance |
Yes, EPA 2020 approved |
| Fuel type |
Dry cordwood |
| Maximum log length |
18" |
| Log positioning |
Loading over width |
| Chimney diameter |
6" |
| Flue outlet diameter |
6" |
| Type of chimney |
UL 103 HT (2100 °F) |
| Minimum chimney height |
12' |
| Baffle material |
Vermiculite |
| Approved for an alcove installation |
Yes |
| Approved for a mobile home installation |
Yes, with fresh air intake |
| Shipping Weight |
336 lb (153 kg) |
| Door type |
Single, glass with cast iron frame |
| Glass type |
Ceramic glass |
| Glass surface – dimensions (Width X Height) |
15 3/4" x 9 3/8" |
| Glass air-wash system |
Yes |
| Overall dimension (Height) |
30 3/8" |
| Overall dimension (Width) |
24 7/8" |
| Overall dimension (Depth) |
23 1/4" |
| Door opening – dimension (Height) |
8 3/4" |
| Door opening - dimension (Width) |
17 1/4" |
| Firebox – dimension (Height) |
11 7/8" |
| Firebox – dimension (Width) |
19 5/8" |
| Firebox – dimension (Depth) |
13 1/2" |
| Firebox lined with refractory bricks for better heat distribution |
Yes |
| Stainless-steel secondary-air system improving gas combustion |
Yes |
| Model |
Legs or pedestal |
| Steel thickness – body |
3/16" |
| Steel thickness – top |
5/16" |
| USA standard (emissions) |
EPA |
| USA standard (safety) |
UL 1482, UL 737 |
| Tested and listed as per applicable standards |
By an accredited laboratory |
| Warranty |
Limited lifetime |
Clearances to Combustibles
Osburn publishes these as lettered dimensions A to F that are defined on the clearance drawings in the installation manual, not in words — so read this table with the manual open rather than assuming which letter is which wall. For planning, the controlling figure is the smallest: 10" with a single-wall connector pipe, 6" with a double-wall connector pipe (USA). The 1700's optional side panels reduce clearances further.
| Dimension |
Single wall (USA) |
Double wall (USA) |
| A |
13" (330 mm) |
6" (152 mm) |
| B |
10" (254 mm) |
10" (254 mm) |
| C |
12" (305 mm) |
6" (152 mm) |
| D |
16 1/2" (419 mm) |
9 1/2" (241 mm) |
| E |
19" (483 mm) |
19" (483 mm) |
| F |
20 3/4" (527 mm) |
14 3/4" (375 mm) |
Mobile Home Installation
Approved with a fresh air intake and a double-wall connector pipe. Same lettered dimensions:
| A |
8" (203 mm) |
| B |
14 1/2" (368 mm) |
| C |
12" (305 mm) |
| D |
11 1/2" (292 mm) |
| E |
23 1/2" (597 mm) |
| F |
20 3/4" (527 mm) |
Floor Protection
On a combustible floor a non-combustible pad must extend 16" (406 mm) in front of the door opening and 8" (203 mm) to each side and to the rear. The installation guide below gives the full pad dimensions for each configuration, plus the alcove and lowered-ceiling clearance sets.
