Empire Horizontal Direct-Vent 2-Ft Rise Kit

Empire Horizontal Direct-Vent 2-Ft Rise Kit

The Empire DVKHP45 is the horizontal termination vent kit for Spirit direct-vent stoves: a 24" vertical rise off the stove, then a 90° elbow out through the wall. The manual approves it for all four Spirit direct-vent stoves on natural gas and propane.

Fits

• Empire Spirit Small Direct Vent Gas Stove
• Empire Spirit Small Cast Iron Direct Vent Gas Stove
• Empire Spirit Medium Cast Iron Direct Vent Gas Stove
• Empire Spirit Medium Steel Direct Vent Gas Stove

Specifications

Installation Notes

• Vent limits: minimum vertical rise before any elbow is 12" (DVP20 and DVP30 natural gas) or 24" (DVP30 propane); sidewall venting allows up to 25 ft vertical and 12 ft horizontal (see the venting graph in the manual); at most two 90° elbows (subtract 5 ft of horizontal run for the second) and two 45° elbows, each 45° in the horizontal run taking 18" off the allowed run.
• Termination: the wall hole is 10" high x 9" wide for 4" x 6 5/8" pipe; the bottom of the cap must be at least 12" above ground, the top at least 18" below a combustible projection, and the cap at least 9" from a parallel wall. Keep combustibles (including siding) 3" from the top of the pipe and 1" from the sides and bottom.

Downloads

• Installation Instructions and Owner's Manual, Spirit Cast Iron Direct-Vent Stoves DVP20CC/DVP30CC (41378)
• Installation Instructions and Owner's Manual, Spirit Steel Direct-Vent Stoves DVP20MS/DVP30MS (42639)

Warranty

Empire's warranty in the stove's installation manual covers remote controls, thermostats, accessories and replacement parts for 1 year (parts), for the original purchaser. Full terms are in the warranty section of the installation manual.
