Emipre Spirit Small Cast Iron Direct Vent Gas Stove

SKU DVP20CC30FP
Original price $0.00 - Original price $0.00
Original price $0.00
$3,019.00
$3,019.00 - $3,639.00
Current price $3,019.00
Ignition Type: Millivolt
Fuel Type: Propane
Finish: Matte Black
  • FREE SHIPPING : All Over United States

  • NO SALES TAX : All USA Orders/except WI

  • SPEAK TO AN EXPERT : Call 888-486-2909 or email at cs@dreamwoodliving.com

Emipre Spirit Small Cast Iron Direct Vent Gas Stove

Bring timeless charm and reliable warmth to your home with the Emipre Spirit Small Cast Iron Direct Vent Gas Stove. Built from durable cast iron, this direct vent gas stove combines traditional design with modern heating efficiency, making it an ideal addition to any living space.

The direct-vent system uses two vent pipes—one drawing in fresh outdoor air for combustion and the other safely exhausting by-products outside. This sealed combustion chamber, paired with a large glass front, ensures clean operation while allowing you to enjoy the beauty of the flames.

For enhanced comfort, room air circulates around the chamber, and an optional blower helps distribute heat evenly throughout your home. Designed for flexibility, the Spirit Gas Stove can be installed along an exterior wall for a shorter vent run or vented vertically through the roof.

Advantages:

  • Good efficiency – 60 to 80%
  • Good heat output with thermal transfer through the glass and air circulation
  • Separates room air from combustion air
  • May be used as primary heat source
  • Can operate with a remote or thermostat
  • Most systems can provide life-saving heat during a winter power outage

Empire Cast Iron Stoves

Direct-Vent Spirit Stoves include Empire’s Slope Glaze Burner system with expanded ember bed for extra glow. Ceramic beads within the burner swirl and tumble the gas to create naturally swirling flames that are indistinguishable from a wood fire. Topped off with the hand-painted ceramic fiber log set and glowing embers, the effect is stunningly realistic and guaranteed to keep you and your guests mesmerized for hours.

Choose from two sizes (20,000 or 27,000 Btu) and three colors – porcelain black, porcelain mahogany, and matte black.

Spirit Stoves are available in two types of ignition.

i) Millivolt (MV)

Empire Cast Iron Stoves are available in two types of ignition – Millivolt (MV) and Intermittent Pilot (IP). The Millivolt system lights a standing pilot with a pushbutton piezo ignitor. Once the standing pilot is lit, the MV system operates with an on/off switch concealed on the back of the stove or with one of Empire’s optional remote control systems.

ii) Intermittent Pilot (IP)

IP systems eliminate the standing pilot for even greater energy savings. Pressing the on/off switch ignites the pilot, which then ignites the main burner. IP systems can also operate with an optional remote control system.

Includes AC Power Adaptor (120VAC) with battery backup (switches to battery during power outage)

Features

  • Upto 20,000 BTUs Slope Glaze Burner
  • Richly detailed casting
  • Decorative cast iron doors (non-operable)
  • Available in three finishes: porcelain black, porcelain mahogany, and matte black
  • Optional side shelf sets available
  • Optional floor pads available
  • Traditional cast iron stove look
  • Your choice of finish and fuel type
  • Compact design with big heat output

Available Models

  • 22" Direct Vent Gas Stove 20,000 BTUs
  • 28" Direct Vent Gas Stove 27,000 BTUs

Includes

  • 4-piece Log Set
  • Fireplace Barrier Screen

Requires

  • 45-Degree Elbow
  • RCK20 Replacement Control Cover required for RVKN or RVKP

Specifications

Model DVP20CC
Dimensions 24 1/8" (H) x 21 1/2" (W) x 16 1/2" (D)
Dimensions with Shelves 24 1/8" (H) x 33 3/4" (W) x 16 1/2" (D)
Venting 4x6 5/8" (Use Black where visible)
Pallet Quantity 4
Gas Type Natural Gas / Propane Gas
Input BTU/HR (KW/H) Max (Propane) 19,500
Input BTU/HR (KW/H) Min (Propane) 13,500
Input BTU/HR (KW/H) Max (Natural Gas) 19,500
Input BTU/HR (KW/H) Min (Natural Gas) 13,500

CLEARANCES

Top of appliance (ceiling) 36 inches
Rear Wall 2 inches
Side Wall 6 inches
Heater Corners (45° angle) to Wall 4 inches
Floor 0 inches

Optional Accessories

Liners


Surrounds


*Bottom Covers for 1-piece Metal Surround available in both finishes.


Fronts


**Requires 1-piece Metal Frame for installation.

Downloads

Warranty

  • 10-year limited warranty on combustion chamber, limited lifetime on glass.
  • All other parts carry a three-year limited warranty.
  • All remote controls carry a one-year limited warranty.

Emipre Spirit Small Cast Iron Direct Vent Gas Stove
